Type of Pump | Displacement | Direction of Rotation | Max. Rotating Speed (rpm) | Max. Pressure | ||||||
continuous | peak | |||||||||
cm3 | Cu.in | continuous | peak | MPa | psi | MPa | psi | |||
VIOPU-30-L | 12 | 0.012 | 0.0007 | CW&CCW | 5000 | 6000 | 30 | 4350 | 35 | 5075 |
16 | 0.016 | 0.0010 | CW&CCW | 5000 | 6000 | 30 | 4350 | 35 | 5075 | |
20 | 0.020 | 0.0012 | CW&CCW | 5000 | 6000 | 30 | 4350 | 35 | 5075 | |
30 | 0.030 | 0.0018 | CW&CCW | 5000 | 6000 | 30 | 4350 | 35 | 5075 | |
45 | 0.045 | 0.003 | CW&CCW | 5000 | 6000 | 30 | 4350 | 35 | 5075 | |
环境温度：175°C
环境压力：140MPa
油液粘度：3-500cSt
油液清洁度：NAS 1638 class
无
